ESO Series – Wall-Mounted Water Level Sensor and Overflow Drain
SHARE:
ESO Series – Wall-Mounted Water Level Sensor and Overflow Drain
Function
The ESO Series is a wall-mounted combination water level sensor and overflow drain. Automatically monitors quick fill and safe-off functions, and drains over flow water through a built-in drain. Integral adjustments on level sensors and standpipe facilitate adjustments after installation. Low voltage for safety. Connects to Crystal Fountains ECL series control panel.
Specifications
- Available in 3/4" electrical connection and 3" drain connection
- 24VAC
- Includes up to three operations: Quick Fill, Safe Off and Max Level Control
- Brass or stainless steel covers available
- PVC, cast bronze and brass
- NPT and BSPT threading available
- IP68 Rated
- UL Rated
SKU : ESO100, ESO101, ESO200, ESO201, ESO300, ESO301 Category Electrical Sensors Tags Stainless Steel, Bronze, Wall-Mounted, Brass, Water Level Sensor, 24VAC, PVC
ESO-REVIT MODEL
7 downloads808.00 KB
ESO100-101-ELEV CAD BLOCK
11 downloads44.38 KB
ESO100-101-INSTALLATION
41 downloads46.63 KB
ESO100-101-PLAN CAD BLOCK
7 downloads43.31 KB
ESO100-CUTSHEET
133 downloads404.71 KB
ESO101-CUTSHEET
42 downloads405.11 KB
ESO200-201-ELEV CAD BLOCK
9 downloads44.38 KB
ESO200-201-INSTALLATION
9 downloads25.34 KB
ESO200-201-PLAN CAD BLOCK
2 downloads43.31 KB
ESO200-CUTSHEET
55 downloads416.67 KB
ESO201-CUTSHEET
19 downloads417.14 KB
ESO300-301-ELEV CAD BLOCK
14 downloads44.37 KB
ESO300-301-INSTALLATION
20 downloads48.86 KB
ESO300-301-PLAN CAD BLOCK
12 downloads43.31 KB
ESO300-CUTSHEET
84 downloads441.40 KB
ESO301-CUTSHEET
25 downloads442.05 KB
